Advantages and Features
High-precision:
The precise fit between the V-shaped roller and the V-shaped guide rail ensures the high-precision operation of the guide rail system, with a repeat positioning accuracy of up to micrometer level.
High rigidity:
Due to the large contact area between the V-shaped roller and the guide rail, the V-shaped roller guide rail has higher rigidity and can withstand larger loads, making it suitable for heavy-duty and high-speed application scenarios.
Low friction:
The V-shaped roller adopts rolling friction, with low friction coefficient, smooth operation, low noise, and low energy consumption.
Long lifespan:
The V-shaped roller and guide rail are made of high-quality steel, which has undergone special heat treatment and surface treatment, and has excellent wear resistance and fatigue resistance, with a long service life.
Maintenance free:
The V-shaped roller guide rail adopts a sealed structure, which can effectively prevent dust and impurities from entering, without lubrication, reducing maintenance costs.
Easy installation:
The V-shaped roller guide rail has a simple structure, easy installation, and can be freely combined according to needs to meet the needs of different application scenarios.
Application scenarios
The V-shaped roller guide is widely used in various situations that require high-precision, high rigidity, and long-life linear motion.
Machine tool industry: CNC machine tools, machining centers, grinders, lathes, etc.
Automation equipment: industrial robots, automatic assembly lines, logistics conveying systems, etc.
Semiconductor equipment: wafer cutting machines, packaging machines, testing equipment, etc.
Medical equipment: CT machines, MRI machines, surgical robots, etc.
Precision instruments: optical instruments, measuring instruments, testing equipment, etc.
Instructions for Use
When installing the V-shaped roller guide rail, ensure that the installation reference surface of the guide rail is flat and clean.
Special tools should be used during installation to avoid damage to the guide rails and rollers.
During operation, the wear of the guide rails and rollers should be regularly checked, and the dust and impurities on the surface of the guide rails should be cleaned in a timely manner.
If it is necessary to replace the roller or guide rail, original accessories should be used and installed and debugged according to the instructions.
Frequently Asked Questions
What is the load-bearing capacity of the V-shaped roller guide rail?
The load-bearing capacity of V-shaped roller guides depends on the specifications and models of the guides. Generally speaking, the load-bearing capacity of V-shaped roller guides is greater than that of traditional ball guides.
What is the operating speed of the V-shaped roller guide rail?
The running speed of V-shaped roller guide depends on the specifications and models of the guide, as well as the specific requirements of the application scenario. Generally speaking, V-shaped roller guide can meet the needs of high-speed operation.
What is the service life of V-shaped roller guide rails?
The service life of V-shaped roller guide depends on the specifications and models of the guide, as well as the usage environment and maintenance situation. Generally speaking, the service life of V-shaped roller guide is longer than that of traditional ball guide.
